Wire Closing Machines

Manual and electric wire closing machines available to order online. We can supply manual wire closing machines for people looking to wire bind infrequently or we can offer electric wire closers that can speed up productivity and are perfect for a busier business or bindery. The closing equipment we offer can close documents as wide as 700mm, ideal for large calendars or art pads. Please ask for information on what closing machine would be best for your individual needs.

Showing all 9 results

  • Renz DTP 340M

    Renz DTP 340M

    5 out of 5
    Sale! £2,295.00 £2,122.87 ex Vat | £2,547.44 inc.VAT

    Renz DTP 340M

    The Renz DTP 340M Punching Machine is a high capacity electric paper punch and is the base for your small bookbindery.  The Renz DTP 340M is space saving but heavy duty at the same time.  The punching capicity is 35mm and punch cycle takes only 1 second.  A full range of wire, spiral and comb dies are available and are all interchangeable, so it takes less than a minute to switch dies.

    Get a FREE Renz HT 330L Pouch Laminator when you purchase a DTP 340M.  While Stocks last!!

    2 free boxes of Renz wire included (please state colour, size, diameter and pitch at checkout).  Free next day delivery.  2 year warranty and an on-going 30% discount on genuine Renz ring wire!

    • Expandable to Modular Binding System (MBS) for Ring Wire, plastic comb or coil binding.
    • Easily punches up to 20.000 sheets/h (70/80 gr.m²).
    • Electrically operated by foot switch.
    • The new drive system saves energy. Motor runs only if foot switch is pressed and will stop immediately after releasing.
    • Punching width up to max. 2 x 34 cm (2 x 13″).
    • Perforating twice=double length.
    • Adjustable lay-edge-guide.
    • Large capacity waste tray.
    • All punching dies, except spiral binding, are delivered with individually removable pins for fast and easy adjustment to size. Pins for spiral binding dies can only be adjusted for A4 and A5 size (8 1/2″ and 11″).
    • Change dies in less than 1 minute with new quick-release screws.

    Technical Data:

    • Length: 36 cm (14 1/4″)
    • Width: 49 cm (19 3/8″)
    • Height: 25 cm (9″)
    • Weight: 40 kg (88 lbs.)
    • Working width: 34 cm (13″)
    • Motor: 230 V / 50 Hz / 0,25 kW or 115 V / 60 Hz / 250 W

    Sale price is for stand alone Renz DTP-340M machine with no dies or binding modules.


  • Renz WP 300 'easy' Wire Dispenser

    Renz WP 300 ‘easy’ Wire Dispenser

    Sale! £900.00 £832.50 ex Vat | £999.00 inc.VAT

    New! The Renz WP 300 ‘easy’ is a fantastic manual wire dispenser that will sit on top of a Renz ECL 360 or special module plate with a WBS 360.  This machine will insert wires vertically and dispense wires from 1/4″ up to 5/8″ in diameter

    Why you’ll love it!

    • Extremely quick adjustment for fast wire diameter set up
    • Speed up production and efficiency, while keeping simplicity
    • No more tricky wire tangles!
    • This module sits on a Renz ECL 360 or special module plate for the WBS 360
    • ,Heavy duty construction, compact design
    • Quality ‘Made In Germany’

    How to use the WP 300 ‘easy’

    3 easy steps to inserting your Renz binding wires in to your documents

    1. Place the pack of wires in the top of the machine
    2. With one simple turn of the knob the wire is released from the wire pack
    3. Watch the wire drop in to your pre-punched documents and remove it to be closed

  • Renz WP 300 Electric Wire Dispenser

    Renz WP 300 Electric Wire Dispenser

    Sale! £3,745.00 £3,464.12 ex Vat | £4,156.94 inc.VAT

    The Renz WP 300 is an electric wire dispenser for Wire Binding. This machine can speed the binding process up by 70% compared to standard methods.


  • Renz WBS 360 Wire Closing Machine

    Renz WBS 360 Wire Closing Machine

    Sale! £510.00 £471.75 ex Vat | £566.10 inc.VAT

    An Easy-to-Use Wire Closing Machine

    The Renz WBS 360 Wire Closing Machine is a wire binding module that can be used as a stand alone machine or attached to a Renz DTP 340 M to create a full wire binding system.


  • Renz Module Holding Device

    Renz Module Holding Device

    Sale! £65.00 £60.11 ex Vat | £72.13 inc.VAT

    Provides stability for the binding modules WBS 340, CBS 340, CCS 340 or PBS 340, when used separately.


  • Renz Wire Clamp

    Renz Wire Clamp – Clampy

    Sale! £45.00 £41.61 ex Vat | £49.93 inc.VAT

    Magnetically affixes to the ECL range of electric closing machines with a working width of 360mm (14.2″).

    Holds wires securly for the insertion of pages. It can also be used with other wire binding systems.


  • Renz ECL 700 Electric Wire Closing Machine

    Renz ECL 700 Electric Wire Closing Machine

    Sale! £4,495.00 £4,157.86 ex Vat | £4,989.43 inc.VAT

    The Renz ECL 700 Electric Wire Closing Machine is an electric wire closer that has a working width of up to 700mm and will close wires in diameter from 3/16″ up to 1 1/2″.  This electric wire clsoer speeds up production and is opearated by foot pedal, allowing the used to have both hands free for full control of the book or document being bound.

    Benefits of choosing the Renx ECL 700:

    • Total control over document
    • Safe – integrated devices providing optimal operator protection
    • Professional machinery
    • Quick and easy adjustments

    Technical data:

    •     Work width up to 700 mm (27.5″)
    •     Up to 2.000 closing cycles per hour with or without calendar hangers
    •     For all binding elements up to 38 mm = 1 1/2″ regardless of pitch
    •     Integrated safety device helps prevent finger injuries and provides optimal operator protection
    •     Heavy duty closing machine for professional use
    •     Quick and easy adjustment to wire diameter takes only a few seconds
    •     Integrated hanging device
    •     Connection: 115 V / 60 Hz or 230 V / 50 Hz
    •     Dimensions L x W of x H: 21″ x 34″ x 10″ (53 x 85 x 24 cm) 150 lbs. (68 kg)

    The Renz ECL-700 now comes with a full 2 year warranty.


  • Renz ECL 500 Electric Wire Closing Machine

    Renz ECL 500 Electric Wire Closing Machine

    Sale! £3,495.00 £3,232.86 ex Vat | £3,879.43 inc.VAT

    The Renz ECL 500 Wire Closing Machine is an electric Wire closer with a working width of 500mm and will close wires diameters of 3/16″ up to 1 1/2″.  This wire closer is operated by foot pedal and therefore gives the used both hands to have complete control over the document.

    Why we love the Renz ECL 500:

    • Accurate control
    • Integrated safety elements
    • Easy adjustments

    Technical data ECL 500

    •     Working width up to 500 mm (20″)
    •     Up to 1.500 closing cycles per hour with or without calendar hangers
    •     For all binding wires up to 38 mm = 1 1/2″ regardless of pitch
    •     Integrated safety device helps prevent finger injuries and provides optimal operator protection
    •     Solid metal construction, suitable for book binderies, copy shops, in-house printing departments, etc.
    •     Quick and easy adjustment to wire diameter takes only a few seconds
    •     Integrated binding part
    •     Connection: 115 V / 60 Hz or 230 V / 50 Hz
    •     Dimensions L x W x H: 21″ x 25″ x 8″ (53 x 64 x 20 cm)
    •     Weight: 88 lbs (40 kg)

  • Renz ECL 360 Electric Wire Closing Machine

    Renz ECL 360 Electric Wire Closing Machine

    Sale! £2,495.00 £2,307.86 ex Vat | £2,769.43 inc.VAT

    The Renz ECL 360 Wire Closing Machine is an electric wire closer that has a working width up to 360mm and will close wites from 3/16″ up to 1 1/2″ in diameter.  Operated by electric foot pedal, this means both the operators hands are free to have full control over the book or document when binding.

    Why we love the Renz ECL 360 Wire Closing Machine:

    • Good accuracy – full control over document when binding
    • Quick and easy adjustment to wire diameter takes only a few seconds
    • Great value

    Technical data

    •     Working width up to 360 mm (14.2″)
    •     Up to 1.500 closing cycles per hour with or without calendar hangers
    •     For all binding elements up to 38 mm = 1 1/2″ regardless of pitch
    •     Integrated safety device helps prevent finger injuries and provides optimal operator protection
    •     Solid metal construction, suitable for book binderies, copy shops, in-house printing departments, etc.
    •     Integrated  hanging device
    •     Connection: 115 V / 60 Hz or 230 V / 50 Hz
    •     Dimensions L x W x H: 21″ x 20″ x 8″ (53 x 50 x 20 cm)
    •     Weight: 63.8 lbs (29 kg)

    Product overview PDF

    SPECIAL OFFER: 2 free boxes of Renz wire included (please state colour, size, diameter and pitch at checkout).  Free next day delivery.  2 year warranty and an on-going 30% discount on genuine Renz ring wire!
